BMC

BMC Roadmachine 01 THREE

$11,499.00
$11,499.00
$11,499.00
Tax included.
If what you're looking for is unavailable call our store 1300 436 379
All bikes need to be COLLECTED IN STORE or delivered locally by Hendry's.
Due to our dealer agreements and manufacturer guidelines, all bikes sold from Hendry's must be fully assembled, and inspected to conform with warranty requirements which prohibits shipping.
Size:
Color: Metallic Red Brown / White

The all-new Roadmachine 01 is faster than ever while still entirely appropriate for every surface. The Roadmachine 01 THREE features Stealth Cable Routing, built-in downtube storage, ICS2 stem and carbon bar combination, complimented with SRAM Force AXS groupset and CRD-321 Carbon Wheelset with road-smoothening 30 mm tires.

Overview

Specifications

Sizing

Overview

The all-new Roadmachine 01 is faster than ever while still entirely appropriate for every surface. The Roadmachine 01 THREE features Stealth Cable Routing, built-in downtube storage, ICS2 stem and carbon bar combination, complimented with SRAM Force AXS groupset and CRD-321 Carbon Wheelset with road-smoothening 30 mm tires.

Specifications

Frame

Roadmachine 01 Premium Carbon with Tuned Compliance Concept Endurance. ICS Technology Stealth Cable Routing. Integrated Downtube Storage. Stealth Dropout Design. 12 x 142mm Thru-Axle

Fork

Roadmachine 01 Premium Carbon with Tuned Compliance Concept Endurance. Flat Steerer Fork. Stealth Dropout Design. Internal Cable Routing. Flat Mount Disc.12 x 100mm Thru-Axle

Stem

BMC ICS2. Integrated Cockpit System Technology

Handlebar

Easton EC70 SL Carbon or Easton EC90 SLX Carbon

Seat

Roadmachine 01 Premium Carbon D-Shaped Seatpost. 15mm Offset D-Fender Compatible

Saddle

Fizik Argo Tempo R5. 150mm

Drivetrain

SRAM Force

Chainrings

46-33T

Cassette

SRAM Force XG-1270

Cassette Size

10-36T

Chainrings

SRAM Apex

Front Derailleur

SRAM Force eTap AXS

Rear Derailleur

SRAM Force eTap AXS

Shifters

SRAM Force eTap AXS

Gears

2 x 12

Bottom Bracket

PF86 Bottom Bracket

Brake Levers

SRAM Force eTap AXS


SRAM Centerline X

Rotor Size

160 160mm

Wheels

CRD-321 SL Carbon. Tubeless Ready  35mm

Hubs

CRD-321 SL

Tyres

Vittoria Corsa N.EXT G2.0 TLR (Tubeless Ready) 30mm


Tubeless Ready Rims Tubetype Tires

Accessories

Integrated Rear Light 20. Roadmachine Bottle Cages. Storage Pouch

Sizing

Size475154565861
Rider Height<160158-174172-180178-186184-192>190
Reach370379383388393398
Stack525550570595620645
Bar Drop127127127127127127
Bar Reach676767676767
Bar Width400420420420420420
BB Drop757575757575
Crank Length170170172.5172.5175175
Fork Length379379379379379379
Fork Rake505045454545
Front Center579596594607620633
Head Tube112138154181207233
Head Tube Angle71.471.472.272.272.272.2
Rear Center415415415415415415
Seat Angle74.274.274.274.274.274.2
Seat Tube414461488508529550
Seatpost Length330380380380380430
Seatpost Offset151515151515
Standover Height726762786807828849
Stem Angle-12.5-12.5-12.5-12.5-12.5-12.5
Stem Length90100100110110120
Top Tube520537546559571581
Trail636363636363
Wheelbase9821000997101010231036
